EcoLine D17
-SUITABLE FOR DRIVE AXLE OF TRUCKS -RUNNING WITH HIGH SPEED ON HIGHWAY
KEY FESTURES
Back
Back
Back
 |
• Closed shoulder promoted uniform wear and improved rolling resistance • Z-Zag groove provides good traction performance • Aggressive center lugs help to improve traction in wet ordry conditions for the life of the tread • Meet Smartway Verified standard |
| Size |
Load index & Speed symbols
|
PR | Load Range | Standard Rim |
Max load and Max Air (lbs&psi)
|
Overall Diameter (in inches)
|
Section Width (in inches)
|
Tread Depth (in 32nds)
|
|||
| Dual | Single | ||||||||||
| lbs | psi | lbs | psi | ||||||||
| 295/75R22.5 | 146/143L | 16 | H | 9.00 | 6005 | 120 | 6610 | 120 | 40.24 | 11.54 | 26 |
| 11R22.5 | 146/143L | 16 | H | 8.25 | 6005 | 120 | 6610 | 120 | 41.53 | 11.06 | 26 |
| 11R24.5 | 149/146L | 16 | H | 8.25 | 6610 | 120 | 7160 | 120 | 43.5 | 11.06 | 26 |
