EcoLine D27
-SUITABLE FOR DRIVE AXLE OF TRUCKS -RUNNING WITH HIGH SPEED ON HIGHWAY
KEY FESTURES
Back
Back
Back
 |
• Open shoulder offers good traction and help with heat dissipation • Aggressive pattern and lateral grooves provides tire excellent drive and braking performance • Two main grooves helps to provide good handling performance
|
| Size |
Load index & Speed symbols
|
PR | Load Range | Standard Rim |
Max load and Max Air (lbs&psi)
|
Overall Diameter (in inches)
|
Section Width (in inches)
|
Tread Depth (in 32nds)
|
|||
| Dual | Single | ||||||||||
| lbs | psi | lbs | psi | ||||||||
| 295/75R22.5 | 146/143L | 16 | H | 9.00 | 6005 | 120 | 6610 | 120 | 40.5 | 11.54 | 30 |
| 11R22.5 | 146/143L | 16 | H | 8.25 | 6005 | 120 | 6610 | 120 | 41.78 | 11.06 | 30 |
| 11R22.5 | 149/146L | 16 | H | 8.25 | 6610 | 120 | 7610 | 120 | 43.75 | 11.06 | 30 |
