EcoLine A21
-SUITABLE FOR ALL POSITION AXLE OF TRUCKS -RUNNING WITH HIGH SPEED ON HIGHWAY
KEY FESTURES
Back
Back
Back
 |
• Straight five-rib tread design with four grooves, promotes even wear and provides a smooth ride, improved handling and superior wet traction • The tread sipes design helps prevent abnormal tire wear, enhances heat dissipation, and delivers better traction and handling performance • Tough tread compound and solid shoulder ribs to resist maneuvering scrub |
| Size |
Load index & Speed symbols
|
PR | Load Range | Standard Rim |
Max load and Max Air (lbs&psi)
|
Overall Diameter (in inches)
|
Section Width (in inches)
|
Tread Depth (in 32nds)
|
|||
| Dual | Single | ||||||||||
| lbs | psi | lbs | psi | ||||||||
| 295/75R22.5 | 146/143L | 16 | H | 9.00 | 6005 | 120 | 6610 | 120 | 40.5 | 11.54 | 13.5 |
| 11R22.5 | 146/143L | 16 | H | 8.25 | 6005 | 120 | 6610 | 120 | Under Development | ||
| 11R24.5 | 149/146L | 16 | H | 8.25 | 6610 | 120 | 7610 | 120 | Under Development | ||
