EcoLine A27S
-SUITABLE FOR ALL POSITON AXLE OF TRUCKS -RUNNING WITH HIGH SPEED ON HIGHWAY
KEY FESTURES
Back
Back
Back
 |
• A combination of 3 wavy grooves and lateral sipes on block provide outstanding traction and drainage performance in all weather conditions • Deep tread depth of 20/32nds provides long tread life • Ecoline A27s meet 3 Peak Mountain Snow Flake (3PMSF) criteria for snow traction performance • Sidewall protector ribs preserve casing durability by fighting curbing damage with thick ribs on both sidewalls |
| Size |
Load index & Speed symbols
|
PR | Load Range | Standard Rim |
Max load and Max Air (lbs&psi)
|
Overall Diameter (in inches)
|
Section Width (in inches)
|
Tread Depth (in 32nds)
|
|||
| Dual | Single | ||||||||||
| lbs | psi | lbs | psi | ||||||||
| 225/70R19.5 | 128/126M | 14 | G | 6.75 | 3750 | 110 | 3970 | 110 | 32.08 | 8.94 | 20 |
| 245/70R19.5 | 135/133M | 16 | H | 7.50 | 4540 | 120 | 4805 | 120 | 33.14 | 9.61 | 20 |
| 215/75R17.5 | 135/133L | 16 | H | 6.00 | 4540 | 123 | 4805 | 123 | 30.41 | 8.35 | 19 |
| 265/70R19.5 | 137/134L | 14 | G | 7.50 | 4675 | 110 | 5070 | 110 | 34.02 | 10.31 | 20 |
