EcoWorks A37
SUITABLE FOR ALL POSITON AXLE OF TRUCKS
KEY FESTURES
Back
Back
Back
 |
• Durable tread compound and robust shoulder designed for excellent wear resistance • 3-groove pattern combined with zigzag grooves offering outstanding traction and water drainage • Center lug with diagonal sipes to promote traction in wet or dry conditions for the life of the tread |
| Size |
Load index & Speed symbols
|
PR | Load Range | Standard Rim |
Max load and Max Air (lbs&psi)
|
Overall Diameter (in inches)
|
Section Width (in inches)
|
Tread Depth (in 32nds)
|
|||
| Dual | Single | ||||||||||
| lbs | psi | lbs | psi | ||||||||
| 255/70R22.5 | 140/137M | 16 | H | 7.50 | 5070 | 120 | 5510 | 120 | 36.54 | 10.16 | 17 |
| 11R22.5 | 146/143K | 16 | H | 8.25 | 6005 | 120 | 6610 | 120 | 40.09 | 11.06 | 19 |
| 11R22.5 | 149/146K | 16 | H | 8.25 | 6610 | 120 | 7610 | 120 | 43.06 | 11.06 | 19 |
| 315/80R22.5 | 157/154K | 20 | L | 9.00 | 8270 | 130 | 9090 | 130 | 42.33 | 12.6 | 19 |
| 275/70R22.5 | 148/145L | 18 | J | 8.25 | 6940 | 130 | 6395 | 130 | 37.68 | 10.55 | 19 |
