EcoLine ST22
-SUITABLE FOR TRAILER AXLE OF TRUCKS -RUNNING WITH HIGH SPEED ON HIGHWAY
KEY FESTURES
Back
Back
Back
 |
• Closed shoulder promoted uniform wear and improved rolling resistance • Micro sipes on groove edges resists abnormal or “river wear”, enhances heat dissipation • Stone rejector platforms in center groove for excellent durability |
| Size |
Load index & Speed symbols
|
PR | Load Range |
Max load and Max Air (lbs&psi)
|
Overall Diameter (in inches)
|
Section Width (in inches)
|
Tread Depth (in 32nds)
|
|||
| Dual | Single | |||||||||
| lbs | psi | lbs | psi | |||||||
| ST205/75R15 | 115/110N | 14 | G | 2335 | 95 | 2680 | 95 | 26.93 | 7.95 | 10 |
| ST225/75R15 | 121/117M | 12 | F | 2835 | 95 | 3195 | 95 | 27.95 | 8.78 | 10 |
| ST225/75R15 | 123/119L | 14 | G | 3000 | 110 | 3420 | 110 | 27.95 | 8.78 | 10 |
| ST225/90R16 | 132/127M | 14 | G | 3860 | 110 | 4400 | 110 | 31.34 | 8.66 | 10 |
| ST235/80R16 | 129/125M | 14 | G | 3640 | 110 | 4080 | 110 | 30.39 | 9.02 | 10 |
| ST235/80R16 | 130/126M | 16 | H | 3750 | 115 | 4190 | 115 | 30.39 | 9.02 | 10 |
| ST235/85R16 | 132/127M | 14 | G | 3860 | 110 | 4400 | 110 | 31.26 | 9.05 | 11 |
| ST235/85R16 | 133/128M | 16 | H | 3970 | 120 | 4540 | 120 | 31.26 | 9.05 | 11 |
