EcoLine S11
-SUITABLE FOR STEER AXLE OF TRUCKS -RUNNING WITH HIGH SPEED ON HIGHWAY
KEY FESTURES
Back
Back
Back
 |
• Open designed decoupling groove for enhanced even wear performance • Outer groove and shoulder sipes to extend tire life by protecting against cracking and tearing • Center rib diagonal sipes to promote even wear and grip • Exclusive velvet knurled font design for the high-endseries, offering a more premium texture |
| Size |
Load index & Speed symbols
|
PR | Load Range | Standard Rim |
Max load and Max Air (lbs&psi)
|
Overall Diameter (in inches)
|
Section Width (in inches)
|
Tread Depth (in 32nds)
|
||||||||||
| Dual | Single | |||||||||||||||||
| lbs | psi | lbs | psi | |||||||||||||||
| 295/75R22.5 | 144/141L | 14 | G | 9.00 | 5675 | 110 | 6175 | 110 | 39.92 | 11.73 | 18 | |||||||
|
295/75R22.5
|
146/143L
|
16
|
H
|
9.00
|
6005
|
120
|
6610
|
120
|
39.92
|
11.73 | 18 | |||||||
| 295/75R22.5 | 149/146L | 18 | J | 9.00 | 6610 | 123 | 7160 | 123 | 39.92 | 11.73 | 18 | |||||||
| 11R22.5 | 146/143L | 16 | H | 8.25 | 6005 | 120 | 6610 | 120 | 41.05 | 11.06 | 18 | |||||||
| 11R24.5 | 149/146L | 16 | H | 8.25 | 6610 | 120 | 7610 | 120 | 43.02 | 11.06 | 18 | |||||||
